液压折臂回转伸缩起重机 Hydraulic Knuckle Slewing Telescopic Crane

文章来源：未知添加时间：2016-11-21 15:03


起重机广泛应用于船舶作为装卸设备，具有起重量大，操纵方便，抗冲击，制动性能好，安全可靠，货物装卸高效，适应性好等特点。中国主要船公司在使用各种类型的船舶1000多台液压起重机，液压起重机是一种高技术含量的电气，液压和机械一体化的船舶货物设备，在过程中需要有一定的技术知识技术管理人员，根据其日常维护要求。

关节伸缩式起重机具有体积小，重量轻，适用性强等特点，目前已广泛应用于船舶类型。

Crane is widely used in the ship as a loading and unloading equipment, it has big lifting capacity, ease of manipulation, impact resistance, braking performance, safe and reliable, high efficiency loading and unloading goods and good adaptability and other characteristics. China's major shipping companies in the use of various types of ships more than 1,000 hydraulic cranes, hydraulic cranes is a high technological content of electric, hydraulic and mechanical integration of ship cargo equipment, in the course of the need to have a certain Technical knowledge of the technical management personnel, according to their daily maintenance requirements.

Knuckle telescopic crane with small size, light weight, strong applicability and other characteristics, is now widely used in types of ships.

, Hydraulic Slewing ,Lelescopic,Knuckle Crane
Safety Load (KN)	Max Outreach (m)	Lifting Speed (m/min)	Slewing Speed (m/min)	Luffing Time (s)	Hoisting Height (m)	Slewing Angle (°)	Permissible Heeling (transverse /Longitudinal)(°)	Power (kW)
10	6~20	15	1	60	30	360°	2°/5°	7.5
15	8~22	15	1	60	30	360°	2°/5°	11
20	5~24	15	1	60	30	360°	2°/5°	15
30	8~25	15	0.9	70	30	360°	2°/5°	22
50	12~25	15	0.75	80	30	360°	2°/5°	37
80	12~25	15	0.75	100	40	360°	2°/5°	55
100	12~25	15	0.75	110	40	360°	2°/5°	75
150	12~28	15	0.6	110	30	360°	2°/5°	90
200	16~30	15	0.6	120	35	270°	2°/5°	75×2
250	20~35	15	0.5	130	40	270°	2°/5°	90×2
300	35	15	0.4	140	40	270°	2°/5°	90×2
350	20~40	15	0.5	150	45	360°	2°/5°	110×2
400	20~40	15	0.5	150	45	360°	2°/5°	140×2
450	25~40	15	0.45	160	50	360°	2°/5°	140×2
500	20~40	15	0.45	170	50	360°	2°/5°
